Spur Gear Hobbing Machine Model:- HL-2
| Max. GEAR DIA. to Hob | 72 mm Gear Dia. by 24 mm Hob Dia. |
| WIDTH of Gear | 50 mm |
| PITCH Capacity | Max. 1.25 Module, 20 D.P. |
| Nos. of TEETH cut by Std. & Extra gear | 6 to 102 Teeth all Nos. & 103 to 230 Teeth with some 'odd Nos. lapsed'. |
| Work SPINDLE size | 8,10,13 & 16 mm as per demand |
| Hob Cutter Dimension | 24 x 8 x 16, 32 x 10 x 13 x 24 mm |
| HELIX ANGLE for Cutter | 5 degree max. for spur gear only |
| SHIFTING of Hob Spindle | 15 mm Liner Movement |
| REVOLUTION of Hob spindle. | 310 to 1500 RPM, 16 step High speed available on request. |
| FEED per Rev. of work | 0.063 to 1 mm, 13 step |
| Distance between HEAD STOCK & CENTER BODY | 120 mm Fixed |
| Distance between HEAD STOCK & TAIL STOCK Quill | Max. 115 mm, Min. 50 mm |
| ELECTRICAL Load | 0.8 KW., 3 Phase |
| Floor Space | 600 x 780 mm, Approx. |
| Shipping Dimension & Weight | 800 x 900 x 1500 mm, 650 Kg. Approx. |
STANDARD ACCESSORIES:
* Heavy cast iron TABLE with Oil Reservoir, Wide oil Basin & Tool Case.
* COOLANT Pump with Drive.
* Std. Plunge CAM.
* DEBURRING Attachment.
* 20 SPANNERS Kit with Box.
* Oil Gun.
* Toggle type Centre attachment with heavy thrust bearing for job clamping.
* Built in AUTO switch to start/ stop Auto Cycle, a modern electrical PANEL for full safety & control in steel cabinet.
* Std. set of 44 gear for FEED & INDEX suitable for Teeth cutting up to 40 Nos. & their multiple.
SPECIAL & ADDITIONAL EQUIPMENT :
* Special index change gears.
* Plunge Hobbing Cam as per job.
* Clamping Acce. as per job.
* Special fly cutter for from teeth wheel.
* Piece counting attachment
* Big size WORK SPINDLE with manually quick collate attachment.
* Hob Spindle fly wheel.
* Magazine type automatic loading unloading attachment.
IMPORTANT HINTS :
Our Machine serves satisfactory in precision industries where small gears are used, such as Typewriter, water Meter, Electric Meter, Taxi & Rickshaw Fare Meter, Bicycle Gear-Hub, Wall clock, Time Piece, Household Grinder, Mixer, Table Fan, Telephone Gear Precision Instruments etc.
